Beschrijving
The ASTR brings all the features of the ASTR RS to an affordable price point: from aerodynamic improvements to modern gravel geometry.The ASTR is ready for every fast ride or gravel race on every type of terrain. Just like the ASTR RS, the ASTR has a tire clearance of 47 – 52 mm (52 millimeters with a 1x setup and 47 millimeters with a 2x setup) for increased grip and comfort.Modern performance geometry also requires more stability due to increasingly rough terrain combined with higher speeds. A 71.5-degree headtube angle ensures you have faster steering. The ASTR features a steeper seat tube (74 degrees), making climbing performance and power transfer better than with a less steep seat tube. The product developers kept the chainstays as short as possible to accommodate tyres up to 52 millimetres without losing the feeling of responsiveness when accelerating. In addition, the bottom bracket is a bit lower than on bikes that bet on comfort. This ensures you have more stability at high speed. Finally, the head height is lower, so you sit more aerodynamically on the bike. In summary, this boils down to a modern competitive geometry, tailored for the ambitious gravel racer. With the addition of the ASTR to the lineup, Ridley underscores its ambition to offer everyone the chance to own an ASTR: from ambitious amateurs to the most dedicated pros.
Artikelnummer SBIASTRID088
Merk Ridley
Model Astr
Ontwerp code AST02As
Maat M
Reeks Gravel
Frame ASTR, HM carbon, BB86, TA12x142
Vork ASTR, TA 12×100, Integrated forkcrown diffuser; 50mm rake, D-Shape steerer
Materiaal Carbon
Groepset Classified Rival AXS 1×12
Crank Arm Rotor VEGAST Crank Arm Set 172mm+30mm axl offset
Crank Chainring Rotor Direct Mount 1x Ring 48T
Cassette Classified // 12s // 11-34
Elektrische fiets Nee
Type rem Flat Mount
Achter derailleur SRAM Rival eTap AXS // 12s
Stuur Forza Cirrus Pro Integrated Flared // 90mm – 380mm (cc shifters) – 445mm (cc drops) // 16° flared // Drop 120mm // Reach 70mm
Zadelpen 4ZA Cirrus // 27.2 // 400mm // Zero offset // Black
Zadel Selle Italia Novus Boost Superflow // Manganese Rails // Black
Voorwiel 4ZA Norte G F24TLR – 3BF GEN3 – DT custom
Achterwiel 4ZA Norte G Classified – NO STI
Buitenband Vittoria Terreno Dry TLR // 700x47c // Folding-TLR // Tan Wall
Maximum bandbreedte 700c (*) 52mm (1x drivetrain) / 47mm (2x drivetrain)
Configurable
Kleuren
Specificaties
Basis kleur Black Metallic // 9
Kleur 2 Bronze Gold
Kleur 3 Bronze Gold
Afwerking Blinkend
Geslacht
Vrouwen
Mannen
EAN 5400928656726
Pedalen Niet inbegrepen **
Frame Level Essential Series
Gebruiksstaat Nieuw
Garantieduur 2 jaar (+ 3 jaar na registratie)
